Expanded metal stock list
Home
>
OKUTANI WIRE NETTING,MFG,CO.,LTD.
>
Grating
Please note that stock levels are subject to change due to demand trends and other factors.
Stainless steel expanded metal
L 1000×S 20000、L 1219×S 2438
Aluminum expanded metal
L 1000×S 2000
Stainless steel (SUS304) Expanded metal
Mesh (mm)
Strand size (mm)
Overall thickness (mm)
Bond (mm)
Mesh type
Unit weight (kg/m2)
Open area (%)
L1000
×
S1000
L1000 x S2000(Vertical mesh)
SW
LW
T (Plate thickness)
W
D
3.1
6.0
0.5
0.7
-
0.3
hexagonal pattern
1.79
56.1
○
3.0
8.0
0.5
0.7
-
0.5
hexagonal pattern
1.85
53
○
3.0
8.0
0.6
0.8
-
0.5
hexagonal pattern
2.53
43.3
○
4.0
8.0
0.5
0.8
-
0.8
hexagonal pattern
1.59
64.6
○
7.0
14.0
0.5
1.0
-
1.0
hexagonal pattern
1.13
79.6
○
7.0
14.0
0.6
0.8
-
1.0
hexagonal pattern
1.09
79.9
○
7.0
14.0
0.8
1.0
-
1.0
hexagonal pattern
1.81
72.6
○
7.0
14.0
1.0
1.0
-
1.0
hexagonal pattern
2.27
68.2
○
10.0
20.0
0.8
0.9
-
1.0
hexagonal pattern
1.14
82.4
○
10.0
20.0
1.0
1.0
-
1.0
hexagonal pattern
1.59
78.3
○
14.0
25.0
0.8
1.0
-
1.0
hexagonal pattern
0.91
87.4
○
16.0
32.0
0.8
0.9
-
2.0
hexagonal pattern
0.72
89.6
○
16.0
32.0
1.0
1.1
-
2.0
hexagonal pattern
1.09
86.8
○
16.0
32.0
1.2
1.2
2.6
2.0
hexagonal pattern
1.43
84.4
○
16.0
32.0
1.5
1.7
3.6
2.0
hexagonal pattern
2.53
79.2
○
○ is a stock item.
■Equivalent to XS type. Allover thickness is 1.2mm – 1.4mm
Part #
Mesh (mm)
Strand size (mm)
Overall thickness (mm)
Bond (mm)
Mesh type
Unit weight (kg/m2)
Open area (%)
L1000 x S1000(Vertical mesh)
L1000 x S2000(Vertical mesh)
SW
LW
T (Plate thickness)
W
D
X-31
12
30.5
1.2
1.4
3.0
2.0
hexagonal pattern
2.22
77.2
○
X-32
12
30.5
1.5
1.7
3.7
2.0
hexagonal pattern
3.37
71.0
○
○
X-33
12
30.5
2.0
2.0
4.4
2.0
hexagonal pattern
5.29
62.2
○
○
X-41
22
50.8
1.5
1.7
3.6
3.0
hexagonal pattern
1.84
85.1
○
X-42
22
50.8
2.0
2.0
4.3
3.0
hexagonal pattern
2.88
80.3
○
○
X-43
22
50.8
3.0
3.0
6.6
3.0
hexagonal pattern
6.48
69.4
○
○
X-61
34
76.2
2.0
2.4
5.0
6.0
hexagonal pattern
2.24
87.5
○
X-62
34
76.2
3.0
3.2
6.9
6.0
hexagonal pattern
4.48
81.2
○
X-63B
34
76.2
4.0
4.0
8.7
6.0
hexagonal pattern
7.46
74.7
○
○
○ is a stock item.
■Equivalent to XG type. Allover thickness is 4.5mm – 6.0mm
Part #
Mesh (mm)
Strand (mm)
Allover thickness (mm)
Bond (mm)
Mesh type
Unit weight (kg/m2)
Open area (%)
L1000 x S2000 (Vertical Mesh)
L1000 x S2438 (Vertical Mesh)
L1524 x S3048 (Vertical Mesh)
SW
LW
T (Plate thickness)
W
D
X-11
34
135.4
4.5
6.5
13.7
30
diamond-shaped
13.6
66.8
○
○
X-12
34
135.4
6.0
6.5
14.3
30
diamond-shaped
18.2
61.1
○
○
X-21
36
101.6
4.5
6.0
12.8
10
hexagonal pattern
11.9
68.2
○
○
X-21C
36
101.6
4.5
5.0
10.9
10
hexagonal pattern
9.91
71.0
○
○
○
X-22
36
101.6
6.0
6.0
13.3
10
hexagonal pattern
15.9
61.9
○
○
○
○ is a stock item.
Aluminum expanded metal
Overall thickness 1.2mm – 4.0mm
Material
Part #
Mesh size (mm)
Strand size (mm)
Overall thickness (mm)
Bond (mm)
Mesh type
Unit weight (kg/m2)
Open area (%)
L1000xS2000(Vertical Mesh)
SW
LW
T (Plate thickness)
W
D
A1050
X-31
12
30.5
1.2
1.4
3.0
2.0
hexagonal pattern
0.761
77.2
○
X-32
12
30.5
1.5
1.5
3.3
2.0
hexagonal pattern
1.02
72.5
○
X-33
12
30.5
2.0
2.0
4.4
2.0
hexagonal pattern
1.81
62.2
○
X-42
22
50.8
2.0
2.0
4.3
3.0
hexagonal pattern
0.989
80.3
○
X-43
22
50.8
3.0
3.0
6.6
3.0
hexagonal pattern
2.22
69.4
○
X-63
34
76.2
4.0
4.0
8.7
7.0
hexagonal pattern
2.56
74.7
○
○ is a stock item
0.5t~1.5t
Material
Mesh size (mm)
Strand size (mm)
Mesh type
Unit weight (kg/m2)
Open area (%)
L1000 x S2000(Vertical Mesh)
SW
LW
T (Plate thickness)
W
A1100
7.0
14.0
1.0
1.0
hexagonal pattern
0.78
68.2
○
10.0
20.0
1.0
1.0
hexagonal pattern
0.55
78.3
○
A1050
3.0
4.6
0.5
0.7
hexagonal pattern
0.64
52.6
○
3.1
6.0
0.5
0.7
hexagonal pattern
0.62
54.6
○
4.0
8.0
0.5
0.8
hexagonal pattern
0.55
64.6
○
4.0
8.0
0.8
1.0
hexagonal pattern
1.09
47
○
7.0
14.0
0.5
1.0
hexagonal pattern
0.39
79.6
○
7.0
14.0
0.8
1.0
hexagonal pattern
0.62
72.6
○
10.0
20.0
0.8
1.0
hexagonal pattern
0.44
81.7
○
14.0
25.0
0.8
1.0
hexagonal pattern
0.31
87.4
○
16.0
32.0
1.5
1.5
hexagonal pattern
0.77
80.0
○
○ is a stock item
Please note that stock levels are subject to change due to demand trends and other factors.
